FM MATTSSON - Pressure Bal TMV Low-High Flow 3/4" Mixing Valve - Code: 5193-8070

FM Mattsson Pressure Balance Thermostatic Mixing Valve - Low Flow-High Flow- 3/4" - with fixed temperature knob - Code: 5193-8070

Product Description

The Pressure Balanced Thermostatic Mixing Valve with Triple Cartridge
Technology is designed to meet the demands of commercial environments
where water flow can vary significantly. This advanced variant features a
center cartridge that operates independently during low flow
situations, while all three cartridges activate during periods of high
demand, ensuring a consistent and reliable warm water supply.

Key Features:

• Triple Cartridge System: The center cartridge handles low flow independently, while all three cartridges engage during high demand, ensuring optimal performance at all times.
• Dual Outlets: Supplied with one 20mm outlet and one 15mm outlet to accommodate different plumbing configurations.
• Pre-Plumbed: Comes pre-plumbed with 25mm pipework in and out, simplifying installation and reducing setup time.
• Built-In Strainers & Non-Return Valves: Equipped with built-in line strainers and non-return valves on both hot and cold inlets to protect the system from debris and backflow.

European Quality: Manufactured in Sweden, this valve meets the highest European standards for quality and performance.

Wide Operating Range:

• Operates efficiently across a wide pressure range from 50kPa to 1000kPa, making it versatile for various applications.

Warranty: Includes a 5-year warranty on the cartridge, offering peace of mind and long-term reliability.

Benefits:

• Adaptive Flow Control: The triple cartridge system ensures consistent water temperature and pressure, even as flow demand fluctuates, making it ideal for commercial environments.
• Easy Installation: With pre-plumbed connections and dual outlet options, this valve simplifies installation and reduces the need for additional components.
• Enhanced Protection: Built-in strainers and non-return valves protect the system from debris and backflow, ensuring long-term performance and safety.
• Reliable Performance: Designed to withstand a wide range of pressures, this valve is perfect for commercial buildings where water demand can vary significantly.

Applications:

• Commercial Environments: Ideal for hotels, hospitals, gyms, and other commercial settings where warm water demand can shift between low and high levels.
• Industrial Facilities: Suitable for industrial applications requiring precise temperature control and reliable water flow.
• Multi-Story Buildings: Perfect for buildings with varying water pressure across different floors, ensuring consistent performance throughout.

Choose the Triple Cartridge Pressure Balanced Thermostatic Mixing
Valve for a solution that adapts to fluctuating water demands, ensuring
consistent, reliable, and safe water flow in commercial and industrial
environments.
